Researchers unravel microbial mysteries in quest for better biofuels

Man looking at petri dish held up to a light
Graduate student Rodrigo Cuellar examines strains of Zymomonas mobilis in Professor Jason Peters' Lab at UW–Madison. A team of researchers from the Peters lab selectively disturbed each of the bacterium's genes to identify those required for general survival as well as those needed to thrive in different conditions.
Chelsea Mamott/Wisconsin Energy Institute

Zymomonas mobilis is good at turning sugar into alcohol. Really good.

People in the tropics have used it since ancient times to brew drinks like pulque and palm wine. Today scientists want to harness the bacterium’s fermentation powers to turn plants into sustainable alternatives to fossil fuels.

But despite years of research we’ve known relatively little about what makes this microbe tick.

Now studies by biofuel researchers at the University of Wisconsin–Madison and its partners have identified the genes that Z. mobilis needs to survive and thrive in various conditions and answered a question that has dogged scientists for decades.

Their findings, published in the journal mBio, could help establish Z. mobilis as a new model organism for understanding related bacteria and will inform future efforts to fine tune it for production of biofuels and other chemicals

Pharmaceutical sciences professor Jason Peters got interested in Zymomonas shortly after joining the faculty at UW–Madison’s School of Pharmacy in 2018.

Six people posed for a photo in a lab The Peters Lab: (from left) Amy Enright, Santosh Kumar, Jason Peters, Amy Banta, Ryan Ward, and Rodrigo Cuellar. Chelsea Mamott/Wisconsin Energy Institute

As a geneticist, Peters studies bacteria to address some of the greatest threats to human health: antimicrobial resistance, air pollution, and climate change.

Peters’ work on climate change led him to join the Great Lakes Bioenergy Research Center (GLBRC), a federally-funded hub based at UW–Madison doing basic science to enable cost-effective and environmentally sustainable fuels and products from non-food plants.

In the mid 2000s, Peters was a graduate student under Bob Landick, a professor of biochemistry and GLBRC science director. Back then, biofuel research was focused largely on yeast and another microbe, Escherichia coli

But it turns out that Zymomonas had inherent qualities that made it a natural biofuel star.

It’s more efficient than bakers’ yeast at fermenting sugar into ethanol, and unlike E. coli, it can tolerate high concentrations of the product. It has less than half the genes of its closest relatives, making it relatively easy to manipulate, and yet it doesn’t need a host organism. And it can live with or without oxygen.

“It basically had most of the properties that we wanted to evolve E. coli into,” Peters said. “But it already had them, so we didn't need to evolve it.”

Hands in blue rubber gloves holding a tray of petri dishes
Z. mobilis cultures in the Peters lab. Chelsea Mamott/Wisconsin Energy Institute

A naturally streamlined genome

Z. mobilis is what’s known as a reduced-genome bacterium, genetically streamlined organisms that are easier to study and use industrially than other bacteria whose genetic redundancy can make it harder to understand what each gene does.

“Fewer genes means easier to work with, easier to understand,” said Amy Enright, a doctoral student in Peters’ lab who collaborated on the study. “And so there's a lot of interest in industrial spaces to try to make small genomes and work with small genomes.”

That smaller genome also makes Zymomonas a more efficient biofuel producer. Because it’s not replicating as much of itself (in the form of DNA), Zymomonas can direct more energy and carbon into the fuel.

While scientists can create reduced genome bacteria, experimental genome reduction can result in strains that don’t perform well in certain conditions. Bacteria with naturally reduced genomes have all the benefits of simplicity while also remaining environmentally robust.

“We think what Zymomonas has evolved to do is just do this one thing really, really well,” Enright said.

In order to better understand the organism, Peters’ team developed a method for using a tool called CRISPRi to selectively deactivate – or “knock down” the function – of each of the microbe’s 1,915 protein-coding genes in order to see what they do.

The results identified genes essential for survival as well as those Z. mobilis needs to grow with and without oxygen.

“There’s a need to understand both the anaerobic and aerobic lifestyles of this organism,” Peters said. “There's also fundamental biology that we’re interested in. How can it get away with only having 2,000 genes? How different are the gene networks that control aerobic and anaerobic growth?”

Now Enright is focused on identifying which genes are necessary for Zymomonas to grow in plant biomass that’s been chemically broken down into a broth that microbes can digest.

“That broth has some toxins in it that stress the bacteria out, and so they slow down our fermentation and we get less biofuel,” Enright said.  “I’m interested in figuring out what genes are important for Zymomonas to grow in the presence of those bioenergy-relevant toxins. Then we could, hopefully, engineer Zymomonas – tweak those genes – so that it grows better in those conditions.”

Woman with glasses and blue striped shirt works at a lab bench
Amy Enright demonstrates a multi-channel pipette in her lab on the UW–Madison campus. Chelsea Mamott / Wisconsin Energy Institute

Solving the mystery of respiration

Zymomonas has one quirk that has stumped scientists for three decades.

It’s a type of organism that can adapt to their surroundings by changing how they capture energy. These facultative anaerobes use cellular respiration when oxygen is present, but they are capable of switching to fermentation when there’s no oxygen.

Because respiration is more efficient, they typically grow better with oxygen.

But despite having the genes needed for respiration, Zymomonas actually grows better without it. Even more puzzling, a series of previous studies showed that disrupting respiratory genes actually improved its aerobic growth.

“This is weird, right?” said Michaela TerAvest, a GLBRC co-investigator and professor of biochemistry at Michigan State University who collaborated on the study. “There are very few cases in bacteria where you just delete part of its genome and it grows better. And it was significantly better.”

Indiana University biology professor James McKinlay, who was not involved in the research but published a commentary on another recent paper from TerAvest’s lab, said decades of research seemed to suggest that Z. mobilis is better off without breathing.

But why?

“It was really a mystery,” McKinlay said. Unless Z. mobilis is exempt from the principles of natural selection, respiration must serve some function.

Woman and man looking at glowing petri dish Michaela TerAvest examines Zymomonas mobilis in her lab at Michigan State University. The bacterium has been modified to produce a fluorescent green protein to help scientists assess the effects of genetic modifications. Chelsea Mamott / Great Lakes Bioenergy Research Center

TerAvest had been pondering that question when Peters mentioned a curious result of his study: Knocking down genes in the respiratory pathway actually hindered growth, just the opposite of what previous studies had found.

“I said, ‘I don't think so, Jason.’” TerAvest recalled.

But her interest was piqued.

So TerAvest decided to block a different gene in the respiratory pathway; this time, the resulting strain did not grow with oxygen.

It turns out that all the previous studies had targeted a gene that only partly inhibited respiration. Even with just 10% of their normal respiration activity, those strains were still able to metabolize oxygen into water, TerAvest explained, essentially creating their own anaerobic environment.

“That little bit of respiration was actually really important,” McKinlay said.

Schematic of Zymomonas mobilis electron transport chain
This schematic illustrates the proposed electron transport chain the bacterium Zymomonas mobilis uses to consume oxygen. Magdalena Felczak & Michaela TerAvest

TerAvest’s results, published in mBio, showed that Z. mobilis doesn’t use respiration to capture energy but instead to protect certain enzymes that are sensitive to oxygen.

That’s important not only for understanding how the bacterium works, but also for guiding future efforts to engineer Z. mobilis for industrial use, where unnecessary genes are often eliminated.

Genes in the respiratory pathway account for about 1% of the bacterium’s genome, which would make them a prime target for deletion if they weren’t providing some benefit.

“But you have to be cognizant that if you delete that from Zymomonas, it's going to create a strain that’s intolerant of oxygen,” TerAvest said. “That’s much more difficult to manage industrially than a strain that can tolerate oxygen.”

This work was supported by the U.S. Department of Energy’s Office of Science and Office of Biological and Environmental Research; the National Institute of General Medical Sciences of the National Institutes of Health; and the National Science Foundation Graduate Research Fellowship Program.
